Velosolex Solex 4600 DOT V2 Parts Catalog

Note: this catalog uses the Velosolex Part Numbers

click on each image for a larger view

Velosolex Solex 4600 DOT V2 Parts Catalog

Note: this catalog uses the Velosolex Part Numbers

*note: Although it says in this manual that the jet size is 32 cc, I have never come across a 4600 so equipped. This is the only guide in which I have seen this listed.
*à noter: Je n'ai jamais vu un 4600 avec un gicleur de 32 cc. Ce guide est le seule guide avec ça.

*note: for INDEX 14, Nut, most, if not all, of the 4600 V2s and V3s on which I have worked have had serrated flange hex lock nuts instead of the pictured rectangular nuts. Using the hex nuts instead of the rectangular nuts enables the mechanic to fully assemble the front brake assembly before installing it into the front forks.
